A key part of electrical power distribution is busduct. Also called busway, bus duct provides an alternative means of conducting electricity. Busduct is used in commercial and industrial settings to conduct electricity to power cables or cable bus. Busduct is easy to maintain and flexible, helping to accommodate changing load requirements.
LV Series busway system is a reliable and efficient electrical distribution system with sandwich type construction. It is a safe and robust power distribution system with high electrical efficiency, low voltage drop and high mechanical strength.
The system offers three-phase three-wire, three-phase four-wire and three-phase five-wire power supply distribution, with rated current from 250A to 4000A for aluminium conductor and 400A to 6300A for copper conductor. The system have a rated operation voltage up to 690V(rated insulation voltage up to 1000V) and IP protection up to IP66 and frequency of 50-60Hz.
Constructed with two-piece aluminium housing, LV breaks the barrier of weight as one of the lightest system in the business and offers maximum flexibility. The full aluminium alloy housing with low magnetic flux to avoid hysteresis loss on the distribution system.
LV series busway is insulated with polyester film and epoxy insulation is available as an option. LV series busway system is an ideal choice for various applications including residential, commercial and industrial electrical distribution. From every aspect: performance, flexibility, quality and customer value, LV series is a superior choice for your next installation.
Our team has extensive experience in busduct design and supply, this allows us to provide a total busduct solution from designing the system to testing and commissioning.
And don’t forget when you buy switchboards from us you’ll be guaranteed a top-quality product that meets all the required safety standards. Also, you’ll be getting the benefit of our famous customer service too.
We also stock a range of CT Metering Boards, Temporary Power Boards, and Group Metering Panels (GMPs) suitable for your next project.
Our team has extensive experience in busduct design and supply, this allows us to provide a total busduct solution from designing the system to testing and commissioning as a total solution provider we are able to offer:
Design Switchboards and Distribution has been engaged to supply a Busduct solution for the construction of a large-scale project in Bundamba, Ipswich.
READ MORE
Woolworths Heathwood Distribution Facility is a major project DSD was lucky enough to be a part of supplying their Busduct solution.
